AUO B116XW03-V.2

AUO B116XW03-V.2 is a high-performance 11.6-inch color a-Si TFT-LCD module manufactured by AU Optronics for compact embedded visualization, notebook-class display assemblies, and lightweight industrial monitor applications. This premium LCD panel features sharp 1366 × 768 HD resolution with RGB vertical stripe architecture, delivering clear text readability, smooth graphic rendering, and stable color presentation for portable operator systems and embedded display equipment. The module supports 262K display colors and is built with TN Normally White transmissive technology for bright and responsive screen output.

One of the major highlights of AUO B116XW03-V.2 is its ultra-slim and lightweight engineering. The panel offers approximately 200 cd/m² brightness with a 500:1 contrast ratio, while the integrated white LED backlight system provides uniform illumination, low power consumption, and stable long-duration operation. With only about 3.6 mm thickness and approximately 235 grams maximum weight, this module is highly suitable for compact laptop assemblies, slim industrial terminals, portable testing instruments, and OEM handheld monitor projects where space-saving design is important.

This industrial TFT module has an active viewing area of 256.125 × 144 mm packed inside a mechanical body of approximately 268 × 174.5 mm. AUO B116XW03-V.2 uses a 40-pin 1-channel 6-bit LVDS digital signal interface with 3.3V logic supply and built-in LED driver support, enabling stable high-speed communication with industrial motherboards, mini PCs, ARM boards, notebook controllers, and compact embedded processor units. The panel also supports a standard 60Hz refresh architecture for smooth and flicker-free visual performance.
