PE 3208H1-1F

11,500.00

The PE 3208H1-1F is a 5.5-inch industrial TFT-LCD display module designed for embedded systems, industrial control panels, medical equipment, handheld devices, and compact HMI applications. It features a 720 × 1280 HD resolution, MIPI DSI interface, wide viewing angles, and LED backlight for dependable long-term performance.

Category:
Description

The PE 3208H1-1F is a compact 5.5-inch TFT-LCD module engineered for industrial and professional applications where high-definition image quality and reliable operation are essential. It provides a 720(RGB) × 1280 HD resolution with an active display area of 68.04 × 120.96 mm, making it suitable for portable medical instruments, industrial handheld devices, HMI terminals, smart control panels, and embedded monitoring systems. The overall module dimensions are approximately 70.54 × 130.36 × 2.2 mm, allowing easy integration into slim equipment designs.

The display uses Normally Black, Transmissive TFT technology and supports up to 16.7 million colors through an 8-bit MIPI DSI interface. It delivers a typical brightness of 300 cd/m² with an 800:1 contrast ratio, helping provide sharp image clarity and good readability for menus, icons, text, and industrial graphics. The panel also supports wide viewing angles of 80/80/80/80 degrees, ensuring clear visibility from multiple directions.

The 3208H1-1F includes an edge-lit LED backlight system for lower power consumption, longer service life, and improved reliability compared to older CCFL-based modules. It is designed to operate within a temperature range of -20°C to 70°C, making it suitable for demanding industrial environments and outdoor equipment. The module is commonly used in rugged handheld devices, medical systems, process monitoring equipment, and industrial automation systems.

Key Features:

  • 5.5-inch industrial TFT-LCD display
  • 720 × 1280 HD resolution
  • Normally Black, Transmissive display mode
  • 16.7 million color support
  • 300 cd/m² brightness
  • 800:1 contrast ratio
  • Wide viewing angles of 80/80/80/80 degrees
  • Edge-lit LED backlight
  • 8-bit MIPI DSI interface
  • Active area: 68.04 × 120.96 mm
  • Module size: 70.54 × 130.36 × 2.2 mm
  • Operating temperature: -20°C to 70°C
  • Suitable for industrial HMIs, medical devices, handheld terminals, embedded systems, and automation equipment
