NEC NL6448BC33-54

NEC NL8060BC31-41D is a high-performance 12.1-inch color a-Si TFT-LCD module manufactured by NEC LCD Technologies for advanced industrial visualization and professional machine interface applications. This premium industrial LCD panel features 800 × 600 SVGA pixel resolution with RGB vertical stripe architecture, delivering crisp text readability, stable graphics rendering, and accurate color presentation for machine operator systems and industrial monitor assemblies. The module supports selectable 6-bit / 8-bit digital RGB color input and uses TN Normally White transmissive display technology to provide bright, responsive, and dependable screen performance during continuous-duty operation.

One of the major highlights of NEC NL8060BC31-41D is its industrial-grade optical durability. The display offers high luminance, high contrast, wide viewing angle, and anti-glare surface treatment, allowing reliable readability in factory floors, machine rooms, and embedded control environments. It is equipped with an edge-light dual CCFL backlight system with replaceable lamp architecture, which provides uniform illumination and makes long-term maintenance easier for OEM industrial equipment. Replacement backlight references confirm that this panel uses two CCFL lamps designed for extended industrial service life.

This industrial TFT module has an active viewing area of approximately 246 × 184.5 mm packed inside a rugged mechanical body of about 280 × 210 × 11 mm, making it ideal for OEM industrial monitor assemblies and machine display replacement projects. NEC NL8060BC31-41D uses a 20-pin 1-port LVDS digital interface with selectable 6/8-bit RGB signal architecture, enabling stable communication with PLC systems, CNC display boards, medical controllers, and embedded processor units. The panel also supports reversible scan direction and industrial safety compliance standards for professional equipment integration.
