The PE M104KP1S REV.A is a compact 5.7-inch industrial TFT-LCD module developed for applications where stable image quality, rugged construction, and long-term reliability are important. It offers a 320 × 240 QVGA resolution with an active display area of approximately 115 × 86 mm, making it suitable for industrial HMIs, machine control systems, medical instruments, test equipment, and embedded monitoring devices.
The display uses transmissive a-Si TFT technology and provides clear image performance for menus, text, status screens, and graphical user interfaces. It delivers a contrast ratio of approximately 400:1, helping ensure good readability in industrial environments. The module also offers viewing angles of 60° left, 60° right, 40° up, and 70° down, allowing flexible installation in different panel orientations.
The M104KP1S REV.A supports smooth screen transitions with a response time of approximately 20 ms rise and 40 ms decay. Its rugged industrial construction makes it suitable for continuous operation in factory environments, process control systems, and operator interface equipment. The display is commonly used in industrial machinery, medical systems, CNC equipment, and embedded devices where dependable long-term display performance is required.
Community discussions around older industrial LCD modules often emphasize the importance of confirming connector pinout, backlight type, controller compatibility, and signal interface before replacement or integration into custom systems.
Key Features:
- 5.7-inch industrial TFT-LCD display
- 320 × 240 QVGA resolution
- Transmissive a-Si TFT technology
- Contrast ratio: 400:1
- Viewing angles: 60°/60°/40°/70°
- Response time: 20 ms rise / 40 ms decay
- Active display area: approximately 115 × 86 mm
- Suitable for industrial HMIs, medical devices, CNC systems, automation equipment, and embedded applications
